FOX Float 3 Evol (Snow)

Fox Float Factory Series Logo

Take your riding to the next level of performance and adjustability with the Factory Series FLOAT 3 EVOL. The spring rates can easily be adjusted externally in the main chamber for your riding style and terrain. Fine-tune your plushness independent of your bottom-out resistance and roll stiffness with the EVOL chamber.

The application-specific calibration will soak up even the hardest terrain for all types of riding styles. Fine-tune the "inside ski lift" for your trail sled, and set your tip over and turning capability for your mountain sled or crossover. Stiffen it up for the trail ride, and soften it to ease into those powder turns, all with a few simple external adjustments made by hand.

Specifications

Position: Front Ski
Sled Type: Trail, Mountain or Crossover
Spring: Air
Weight: 3.2 lbs @ 16.6"

Adjustments

Infinitely adjustable dual air spring
- MAIN Air Chamber (ride height)
- EVOL Air Chamber (bottom-out/roll control)

Features

Genuine Kashima Coat
Samurai Sealing System (SSS)
EVOL Air Technology
Aerospace-grade PTFE-lined spherical bearings
High-flow velocity-sensitive damping
Chrome silicone negative spring
Fully rebuildable and revalveable
Lose up to 6 pounds off your sled
(when replacing coil spring shocks)

Kashima Coat

Buttery-smooth, Genuine Kashima Coat is available only from FOX. Its distinctive gold color is backed by its high performance attributes—properties that provide an exceptionally smooth feel and extreme durability.

How Kashima works »

EVOL Air Chamber

The infinitely adjustable pressure setting in the extra volume (EVOL) air chamber regulates spring rate in the final portion of the stroke and controls the bottom-out characteristics of the shock.

How EVOL works »

Infinitely Adjustable Air Spring

FLOATs are the most progressive and adjustable air shock on the market — zero tools are necessary to change plushness.

Learn more »

Velocity-Sensitive Damping Control

One of the most significant components in any shock is its piston and valving … they are the heart of any damper. Every shock in our lineup utilizes our race-proven Velocity-Sensitive Damping Control technology. Through the use of different piston flow designs and variable valving specifications, we are able to custom tune each shock for its intended application.

Samurai Sealing System (SSS)

Working closely with one of the word's leading seal suppliers, FOX Racing Shox has developed our unique dual stage Samurai Sealing System (SSS) for use on all FLOAT 2, FLOAT X, and FLOAT X EVOL air shocks. The seals in the SSS are specifically designed from a special low-temperature, highly durable material that scrapes away snow, ice, and debris while simultaneously keeping the seals lubricated for minimal friction.

Application Listing

Click on application in the list to view more details on the part. All Prices are in Canadien Dollars

	Part No.	Supplier No.	Description	Canadian Retail Price
ARCTIC CAT
	30-85023102	850-23-102	Float 3 Evol Factory Series - Arctic Cat M 9000, 8000, 7000, 6000 (LTD / HCR M9000 / Sno-Pro) 2014-15 - 38"	$1,113.00⁽⁴⁾	Check Stock
	30-85023102	850-23-102	Float 3 Evol Factory Series - Arctic Cat Proclimb M800, M1100, M1100 Turbo (Sno Pro / LTD) 2013 - 38"	$1,113.00⁽⁴⁾	Check Stock
	30-85023102	850-23-102	Float 3 Evol Factory Series - Arctic Cat Proclimb M 800 / 1100 / 1100 Turbo, 38" Ski Stance Arctic Parts and Accessories Kit 2012	$1,113.00⁽⁴⁾	Check Stock
	30-85023203	850-23-203	Float 3 Evol Factory Series - Arctic Cat Crossfire 600 / 800 / 1000 2008-11	$1,113.00⁽⁴⁾	Check Stock
	30-85023203	850-23-203	Float 3 Evol Factory Series - Arctic Cat Crossfire 800 / 1000 2007	$1,113.00⁽⁴⁾	Check Stock
	30-85023203	850-23-203	Float 3 Evol Factory Series - Arctic Cat Cross Fire, Saber Cat 500 / 600 / 700 2004-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023203	850-23-203	Float 3 Evol Factory Series - Arctic Cat Fire Cat F5, F6, F7 2002-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023204	850-23-204	Float 3 Evol Factory Series - Arctic Cat F Series / 500 / 600 / 800 / 1000 2009-11	$1,113.00⁽⁴⁾	Check Stock
	30-85023204	850-23-204	Float 3 Evol Factory Series - Arctic Cat Z1, Z1 Turbo 2009-11	$1,113.00⁽⁴⁾	Check Stock
	30-85023205	850-23-205	Float 3 Evol Factory Series - Arctic Cat M1000, M1000 Sno-Pro (153/162) 2007-08	$1,113.00⁽⁴⁾	Check Stock
	30-85023205	850-23-205	Float 3 Evol Factory Series - Arctic Cat M6 (141/162) 2007-08	$1,113.00⁽⁴⁾	Check Stock
	30-85023205	850-23-205	Float 3 Evol Factory Series - Arctic Cat M8 (141/153/162) 2007-08	$1,113.00⁽⁴⁾	Check Stock
	30-85023205	850-23-205	Float 3 Evol Factory Series - Arctic Cat Mountain Cat M5 / M6 / M7 2004-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023210	850-23-210	Float 3 Evol Factory Series - Arctic Cat Proclimb M800, M1100, M1100 Turbo (Sno Pro / LTD) 2012	$1,113.00⁽⁴⁾	Check Stock
	30-85023211	850-23-211	Float 3 Evol Factory Series - Arctic Cat Procross F 800 / 1100 / 1100 Turbo (Sno Pro / LTD / LXR) 2012-13 - 42-43"	$1,113.00⁽⁴⁾	Check Stock
	30-85023211	850-23-211	Float 3 Evol Factory Series - Arctic Cat Procross XF 800 / 1100 / 1100 Turbo (Sno Pro / LTD / High Country / LXR / Crosstour) 2012-13 - 42-43"	$1,113.00⁽⁴⁾	Check Stock
	30-85023211	850-23-211	Float 3 Evol Factory Series - Arctic Cat XF 9000, 8000, 7000, 6000 (CrossTrek, Crosstour) 2016 - 42-43"	$1,113.00⁽⁴⁾	Check Stock
	30-85023211	850-23-211	Float 3 Evol Factory Series - Arctic Cat XF 9000, 8000, 7000 (LTD / Sno-Pro / LXR / Crosstour / XC Sno-Pro / High Country) 2014-15 - 42-43"	$1,113.00⁽⁴⁾	Check Stock
	30-85023224	850-23-224	Float 3 Evol Factory Series - Arctic Cat M 9000, 8000, 7000, 6000 (LTD / SE / Sno-Pro) 2016 - 36"	$1,113.00⁽⁴⁾	Check Stock
POLARIS
	30-85023200	850-23-200	Float 3 Evol Factory Series - Polaris IQ Shift 550 / 600, Turbo IQ, 550 Shift 136 2012	$1,113.00⁽⁴⁾	Check Stock
	30-85023200	850-23-200	Float 3 Evol Factory Series - Polaris IQ / 600 / 700 / SHIFT, Dragon 600 / 700 / Turbo 2008-11	$1,113.00⁽⁴⁾	Check Stock
	30-85023200	850-23-200	Float 3 Evol Factory Series - Polaris Switchback 600 / 700 / Dragon 2008-11	$1,113.00⁽⁴⁾	Check Stock
	30-85023201	850-23-201	Float 3 Evol Factory Series - Polaris RMK 600 2011	$1,113.00⁽⁴⁾	Check Stock
	30-85023201	850-23-201	Float 3 Evol Factory Series - Polaris RMK SHIFT (600/700), Dragon (700/800) 2008-10	$1,113.00⁽⁴⁾	Check Stock
	30-85023201	850-23-201	Float 3 Evol Factory Series - Polaris RMK 600 HO (144/155), Dragon 700 2007	$1,113.00⁽⁴⁾	Check Stock
	30-85023201	850-23-201	Float 3 Evol Factory Series - Polaris RMK 600 HO (700/800) 2006	$1,113.00⁽⁴⁾	Check Stock
	30-85023202	850-23-202	Float 3 Evol Factory Series - Polaris RMK 900 2005-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023202	850-23-202	Float 3 Evol Factory Series - Polaris RMK (600/700/800) 2002-05	$1,113.00⁽⁴⁾	Check Stock
	30-85023208	850-23-208	Float 3 Evol Factory Series - Polaris Indy 600, Indy 600/800 SP 2013-16 - 42.5"	$1,113.00⁽⁴⁾	Check Stock
	30-85023208	850-23-208	Float 3 Evol Factory Series - Polaris Switchback 600/800, (Pro-R, Pro-S, Pro-X , 600 Adventure, Assault) 2012-16 - 42.5"	$1,113.00⁽⁴⁾	Check Stock
	30-85023208	850-23-208	Float 3 Evol Factory Series - Polaris Rush 600/800, 600/800 Pro-R 2012-14 - 42.5"	$1,113.00⁽⁴⁾	Check Stock
	30-85023209	850-23-209	Float 3 Evol Factory Series - Polaris Pro-RMK 600/800, SKS 800 (155, 163) AXYS 2016	$1,113.00⁽⁴⁾	Check Stock
	30-85023209	850-23-209	Float 3 Evol Factory Series - Polaris Pro-RMK 600/800 2013-15	$1,113.00⁽⁴⁾	Check Stock
	30-85023213	850-23-213	Float 3 Evol Factory Series - Polaris RMK 600 (144, 155) / RMK 800 (155) 2013-16	$1,113.00⁽⁴⁾	Check Stock
	30-85023213	850-23-213	Float 3 Evol Factory Series - Polaris RMK (600/800), (600/800) Pro 2012	$1,113.00⁽⁴⁾	Check Stock
	30-85023213	850-23-213	Float 3 Evol Factory Series - Polaris RMK 800, 800 Pro 2011	$1,113.00⁽⁴⁾	Check Stock
SKI-DOO
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: X / TNT / Sport (550/600/800/1200) 2013-15	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: X / TNT / Sport (550/600/800/1200), Renegade X (600/800/1200) 2012	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: Renegade 600 / 700 / 800 2002-03	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: Adrenaline 600 / 700 / 800 2001-02	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: X 600 / 700 / 800 2001-02	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo GT Fan 380 / 500, GS 600 / 700, SE 600 / 800, Sport 500 / 600 / 700 2002	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo Legend Fan 380 / 500, Sport 500 / 600 / 700 2002	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: Sport, Trail (600 / 700 / 800) 2002	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: Trail (500 / 600 / 700 / 800) 2001	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo Touring 500 / 600, GS 700 2001	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo GT 600 2000	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: 500 / 700 2000	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: X / MXZ Adrenaline / MXZ TNT / MXZ Sport / Renegade 2010-11	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo Renegade: Backcountry, Backcountry X (600/800) RAS-2 2016 - 40"	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo Renegade: X / Adenaline / Sport (600/800/1200) 2013-15	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo Freeride: 137, 146/154 (800) RAS-2 2016 - 40"	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo Freeride 137, 146/154 2014-15 - 40"	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: Fan / 550 X / Trail / TNT / Adrenaline / Renegade / Rev XP 2008-09	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: Fan / 550 X / Trail / Adrenaline / Blizzard / ZX / ZX-RS 2007	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: Adrenaline 500 / 600 / 800 REV 2004-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: Fan 380 / 550 ZX Chassis 2004-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: Renegade / Renegade X 600 / 800 / 1000 REV 2004-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: Trail 500 / 600 REV 2004-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023206	850-23-206	Float 3 Evol Factory Series - Ski-Doo MXZ: 440 / 600 / 800 REV 2003-05	$1,113.00⁽⁴⁾	Check Stock
	30-85023207	850-23-207	Float 3 Evol Factory Series - Ski-Doo Summit: Fan / Adrenaline / Everest / X / Rev XP 2008-10	$1,113.00⁽⁴⁾	Check Stock
	30-85023207	850-23-207	Float 3 Evol Factory Series - Ski-Doo Summit: Fan / Adrenaline / X / Highmark / X-RS 2007	$1,113.00⁽⁴⁾	Check Stock
	30-85023207	850-23-207	Float 3 Evol Factory Series - Ski-Doo Summit: Renegade 800 2001	$1,113.00⁽⁴⁾	Check Stock
	30-85023207	850-23-207	Float 3 Evol Factory Series - Ski-Doo Summit: Highmark 1000 REV 2005-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023207	850-23-207	Float 3 Evol Factory Series - Ski-Doo Summit: Adrenaline 600 / 800 REV 2004-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023207	850-23-207	Float 3 Evol Factory Series - Ski-Doo Summit: Highmark X 800 REV 2004-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023207	850-23-207	Float 3 Evol Factory Series - Ski-Doo Summit: Fan 550 ZX Chassis 2004-05	$1,113.00⁽⁴⁾	Check Stock
	30-85023207	850-23-207	Float 3 Evol Factory Series - Ski-Doo Summit: Sport 800 REV 2004-05	$1,113.00⁽⁴⁾	Check Stock
	30-85023207	850-23-207	Float 3 Evol Factory Series - Ski-Doo Summit: Adrenaline (600/700/800) 2003-05	$1,113.00⁽⁴⁾	Check Stock
	30-85023207	850-23-207	Float 3 Evol Factory Series - Ski-Doo Summit: Highmark (700/800) 2003-05	$1,113.00⁽⁴⁾	Check Stock
	30-85023207	850-23-207	Float 3 Evol Factory Series - Ski-Doo Summit: Fan, Highmark, Highmark X, Sport, X (600/700/800) 2002	$1,113.00⁽⁴⁾	Check Stock
	30-85023212	850-23-212	Float 3 Evol Factory Series - Ski-Doo Summit XM: X / SP / Sport (600/800) 2012-15	$1,113.00⁽⁴⁾	Check Stock
	30-85023212	850-23-212	Float 3 Evol Factory Series - Ski-Doo Summit XM: X / Everest / Sport 2011	$1,113.00⁽⁴⁾	Check Stock
	30-85023221	850-23-221	Float 3 Evol Factory Series - Ski-Doo Summit XM: SP, Burton (600/800) RAS-2 2016 - 36"	$1,113.00⁽⁴⁾	Check Stock
	30-85023221	850-23-221	Float 3 Evol Factory Series - Ski-Doo Summit XM: X, SP (800) T-3 Package 2016 - 36"	$1,113.00⁽⁴⁾	Check Stock
	30-85023221	850-23-221	Float 3 Evol Factory Series - Ski-Doo Summit XM: X T-3 Package 2015 - 36"	$1,113.00⁽⁴⁾	Check Stock
	30-85023222	850-23-222	Float 3 Evol Factory Series - Ski-Doo MXZ: XRS, X, Blizzard, TNT (600/800/900/1200) RAS-2 2016 - 42"	$1,113.00⁽⁴⁾	Check Stock
	30-85023222	850-23-222	Float 3 Evol Factory Series - Ski-Doo MXZ: XRS RAS-2 2015 - 42"	$1,113.00⁽⁴⁾	Check Stock
	30-85023222	850-23-222	Float 3 Evol Factory Series - Ski-Doo Renegade: XRS, X, ENDURO, ADRENALINE (600/800/900/1200) RAS-2 2016 - 42"	$1,113.00⁽⁴⁾	Check Stock
	30-85023222	850-23-222	Float 3 Evol Factory Series - Ski-Doo Renegade: XRS RAS-2 2015 - 42"	$1,113.00⁽⁴⁾	Check Stock
YAMAHA
	30-85023102	850-23-102	Float 3 Evol Factory Series - Yamaha SR Viper MTX 2014-15 - 38"	$1,113.00⁽⁴⁾	Check Stock
	30-85023211	850-23-211	Float 3 Evol Factory Series - Yamaha SR Viper RTX DX/SE/LE, LTX DX/SE/LE 2014-16 - 42-43"	$1,113.00⁽⁴⁾	Check Stock
	30-85023211	850-23-211	Float 3 Evol Factory Series - Yamaha SR Viper XTX SE/LE, STX DX 2014-16 - 42-43"	$1,113.00⁽⁴⁾	Check Stock
	30-85023216	850-23-216	Float 3 Evol Factory Series - Yamaha FX Nytro / FX Nytro RTX / FX Nytro XTX / FX Nytro XTX 1.75 2008-14	$1,113.00⁽⁴⁾	Check Stock
	30-85023216	850-23-216	Float 3 Evol Factory Series - Yamaha FX Nytro MTX (153, 162) 2012-14	$1,113.00⁽⁴⁾	Check Stock
	30-85023216	850-23-216	Float 3 Evol Factory Series - Yamaha FX Nytro MTX SE 2010-11	$1,113.00⁽⁴⁾	Check Stock
	30-85023217	850-23-217	Float 3 Evol Factory Series - Yamaha Apex MTX / SE 2007-10	$1,113.00⁽⁴⁾	Check Stock
	30-85023217	850-23-217	Float 3 Evol Factory Series - Yamaha RS Vector Mountain / SE 2007	$1,113.00⁽⁴⁾	Check Stock
	30-85023217	850-23-217	Float 3 Evol Factory Series - Yamaha RS Vector Mountain / RS Vector Mountain SE 2006	$1,113.00⁽⁴⁾	Check Stock
	30-85023217	850-23-217	Float 3 Evol Factory Series - Yamaha RS Vector Mountain 2005	$1,113.00⁽⁴⁾	Check Stock
	30-85023217	850-23-217	Float 3 Evol Factory Series - Yamaha RX-1 Mountain 2003-05	$1,113.00⁽⁴⁾	Check Stock
	30-85023217	850-23-217	Float 3 Evol Factory Series - Yamaha RX-1 Mountain LE 2003-04	$1,113.00⁽⁴⁾	Check Stock
	30-85023219	850-23-219	Float 3 Evol Factory Series - Yamaha Apex / Apex RTX / Apex SE / Apex XTX 2008-14	$1,113.00⁽⁴⁾	Check Stock
	30-85023219	850-23-219	Float 3 Evol Factory Series - Yamaha RS Vector / RS Vector LTX 2008-14	$1,113.00⁽⁴⁾	Check Stock
	30-85023219	850-23-219	Float 3 Evol Factory Series - Yamaha RS Vector 2005-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023219	850-23-219	Float 3 Evol Factory Series - Yamaha Apex Vector & GT / RS Vector & GT 2008-11	$1,113.00⁽⁴⁾	Check Stock
	30-85023219	850-23-219	Float 3 Evol Factory Series - Yamaha Attack / GT 2007	$1,113.00⁽⁴⁾	Check Stock
	30-85023219	850-23-219	Float 3 Evol Factory Series - Yamaha Nytro / Nytro ER 2007	$1,113.00⁽⁴⁾	Check Stock
	30-85023219	850-23-219	Float 3 Evol Factory Series - Yamaha RS Rage GT / RS Rage 2007	$1,113.00⁽⁴⁾	Check Stock
	30-85023219	850-23-219	Float 3 Evol Factory Series - Yamaha RS Venture / GT 2007	$1,113.00⁽⁴⁾	Check Stock
	30-85023219	850-23-219	Float 3 Evol Factory Series - Yamaha Apex RTX / GT / ER 2006	$1,113.00⁽⁴⁾	Check Stock
	30-85023219	850-23-219	Float 3 Evol Factory Series - Yamaha Nytro / Nytro ER / Apex 2006	$1,113.00⁽⁴⁾	Check Stock
	30-85023219	850-23-219	Float 3 Evol Factory Series - Yamaha RS Rage 2005-06	$1,113.00⁽⁴⁾	Check Stock
	30-85023224	850-23-224	Float 3 Evol Factory Series - Yamaha SR Viper MTX SE/LE 2016 - 36"	$1,113.00⁽⁴⁾	Check Stock
